Filter cloth cleaning machine series

100KG-150KG filter cloth cleaning machine

  • 100KG-150KG filter cloth cleaning machine
  • 200KG-300KG filter cloth cleaning machine
  • 200KG-300KC filter cloth cleaning machine
  • 400KG filter cloth cleaning machine

main features

Adopting a horizontal drum type, both the inner and outer cylinders are made of high-quality stainless steel plates, which are flat, bright, corrosion-resistant, and have little wear and no damage to the fabric. The machine has a long service life;

The inner cylinder door cover is equipped with a stainless steel safety locking mechanism, and the outer cylinder door cover is equipped with an electrical interlock device, ensuring safe and reliable operation;

Adopting triangular tape transmission, it has low vibration, smooth operation, and durability.


Type

Maximum washing capacity

drum(mm)

(kw)power

r/min

(Mpa)  steam pressure

(mm) overall dimensions

GX10

10

φ480*600

0.55

46

0.4-0.6

1030*730*1030

GX15

15

φ540*680

0.75

46

0.4-0.6

1100*800*1140

GX20

20

φ600*700

0.75

42

0.4-0.6

1120*860*1170

GX30

30

φ660*800

1.1

36

0.4-0.6

1520*1100*1300

GX50

50

φ800*980

1.5

36

0.4-0.6

1750*1200*1500

GX70

70

φ950*1220

2.2

34

0.4-0.6

2050*1300*1700

GX100

100

φ960*1420

3

34

0.4-0.6

2300*1300*1800

GX150

150

φ1060*1650

4

33

0.4-0.6

2500*1400*1800

GX200

200

φ1080*2000

5.5

32

0.4-0.6

2900*1400*1900

GX250

250

φ1200*2280

7.5

30

0.4-0.6

3200*1820*2100

GX300

300

φ1300*2280

7.5

28

0.4-0.6

3200*1930*2200

GX400

400

φ1220*3360

11

28

0.4-0.6

4300*1900*2100
